Name: FOSBER BRICQ Common Edge 16m Width Corrugator Belts
Brand: YIKE GROUP
Price: 2 USD

Brand Name : YIKE GROUP

Model Number : YK-1800

Certification : CE

Place of Origin : China

MOQ : 1set

Price : $2,000.00 /set

Payment Terms : T/T, Western Union

Delivery Time : 20 days after deposit

Packaging Details : Standard Packages

Supply Ability : 100,000 meters per Month

Condition : BHS / TCY / FOSBER / BRICQ Common Edge Corrugator Belts

Type : Packaging Line, Corrugated paperboard production line

Packaging type : Standard Packing

Material : 5-layer woven fabric

Feature : Woven structure, anti-skidding

Usage : BHS / TCY / FOSBER / BRICQ Cardboard Production Line

Model : YKK, YKC Common Edge Corrugator Belts

Name : Corrugated board conveyor belt

Contact Now

BHS / TCY / FOSBER / BRICQ Common Edge Corrugator Belts

Introduction

Corrugator belt also named Corrugated board conveyor belt.
Corrugator belt is for corrugated board production line and developed specifically for Double Facer. Corrugator belts consistently keep the fastest absorption & release of moisture, which secures high-quality cardboards with less consumption of heat and energy, and higher speed is assured. Corrugator belts have been specially developed for the transport of board and optimization of the drying process, they resist the stress continuously and achieve as long a life as possible.

Technical Specifications

Type	YKC-Common edge Corrugator Belts
Thickness	(9±0.30)mm
Width	(1600-2800)mm
Heat-resistance	240ºC
Tensile strength	75Mpa
Coefficient of friction	≥0.4u
Weight per unit	(7.5 ± 0.3)kg/m2
Air-permeability	2.2m3/m2min.

Products Features

Tensile strength	Warp direction (63-75) Mpa in dry mode
Heat resistance	Raw materials are polyester synthetic fiber, softening point≥260ºC
Moisture absorption	Quick absorption and emission of heat, therefore cardboard can be quickly dried
Seams	The Belt seam part is fabricated with imported steel fasteners and filled with rubber, flat surface, heat- resistance, fastness, and non-marking
Suitability	Suitable for BHS, JS, TCY, CHAMPION, YIKE GROUP, FOSBER corrugators, various cardboards, and some particular operation modes.
Geometrical dimension	Steady belt dimension, high weaving density, low stretching and contraction, and good contact between belt surface and cardboard.
Service life	As long as the same products are imported abroad.
